Corghi HD500 Plus Truck & Bus Tyre Changer

New model June 2021

The HD500 tyre changer has been completely redesigned to offer you better performance.

The special features of this tyre changer, such as EASE OF USE, COMPACT SIZE, PERFECT TOOL POSITIONING and
WORK SPEED make it an EASY and QUICK machine to use

  • Turntable increased rpm, from 7.5 to 9 rpm
  • New rim clamping jaws
  • New reinforced frame
  • New Control Console with accessorysupport
    ( CONTROL CONSOLE ADJUSTABLE in height 2working heights )
  • New gearbox  unit

The 2 hydraulic-powered trolleys, the chuck holder and the tool carriage, allow the wheel to be moved rapidly.

This always puts it in the best position to be demounted and mounted.

Compact and multi-purpose turntable with hydraulic drive.

This structure was specifically designed to guarantee rapid movement that doesn't waste time or energy

The tyre changer was designed to take up the least amount of space, able to be positioned anywhere inside the garage

Corghi - The worlds most trusted and proven name in tyre changing equipment

  • 100% made in Italy
  • Fully hydraulic
  • Able to clamp rims ranging in size from 14” to 26”
  • Compact and user-friendly tyre changer..
  • the load-bearing structure of the tyre changer, is equipped with new technical solutions to increase
    its robustness when working on particularly heavy wheels.
  • Top-of-the-range clamping jaws.Clamping from 14’’ to 26’’. Maximum performance thanks to the 7 different clamping
    methods available. Minimum clamping diameter: 100 mm. Supplied with plastic rim support plugs in different thicknesses for perfect rim clamping.
  • New control console with separate housings for electrical cables and hydraulic pipes. You can now easily place the different accessories
    on the control console, such as the protections for aluminium alloy rims.
  • The new control console also allows to choose whether to use the standard working height or to raise it thanks to the drilling in the
    structure. The raised position is 150 mm higher than the standard working height.
Bead Breaking Force 14000N
Wheel Clamping 26"
Maximum wheel width 30" 695mm
Max Wheel Diameter 1400mm
Max Wheel Weight 700kg
Hydraulic control unit motor 0.75 Kw (3ph)
Turntable motor 1.1 Kw (3ph)
Max. torque delivery 2200 Nm




ENQUIRE NOW DOWNLOAD BROCHURE
