Artiglio Space Saver Corghi Tyre Changer

Artiglio Space Saver R – Right Rotation

Perfect for Tight Spaces & Mobile Service

The Artiglio Space Saver R is an advanced automatic tyre changer designed for workshops and mobile services where space is at a premium.

Featuring a side-swing post with pneumatic rotation, this innovative design reduces the machine’s operating footprint by almost 1 metre (3.3 ft), making it ideal for confined areas or specialised setups.

Despite its compact size, the Space Saver R delivers exceptional capability:

  • Wheel clamping up to 24” (external)

  • Max wheel diameter: 1035 mm (40.7”)

  • Max wheel width: 14”

  • Compatible with car, SUV, light commercial, and motorcycle wheels (with accessories)

  • Built for intensive, professional use

Precision, Safety & Speed

The rotating post makes operation faster and more ergonomic. The mounting/demounting tool’s unique design ensures accurate, safe handling at every stage, with plastic rim protectors to prevent damage.

The demounting and mounting tool is a major innovation for this tyre changer. A newly developed read tab supports tyre installation, helping guide the bead smoothly onto the rim and reducing the risk of damage – especially effective on RFT, UHP, and BSR tyres when used with the optional bead pressing tool.

Compact Power & Patented Technology

  • High-performance, space-efficient turntable

  • Patented mechanism for wheels from 10” to 26”

  • Quick, easy adjustment between 10”-20” and 14”-24” (external clamping)

The Artiglio Space Saver R is a robust, reliable and workshop-proven solution for any business needing top-tier performance in the smallest possible footprint.





  • Pedal controlled inflation gauge with deflation button
  • Side rotating post
  • Pneumatic locking mechanism automatically gives vertical and horizontal clearance from the rim to avoid scratches on the face of the wheel
  • Powerful bead breaker 15500nm
  • Includes plastic jaw protectors and mounting head inserts
  • Includes lube, lube brush, container & HD tyre lever
  • Includes pneumatic bead depressor
  • Optional ATV or M/C adapters
  • 2 Year Warranty
  • 100% made in Italy
Outside Wheel Clamping 10" - 24"
Inside wheel Clamping 12" - 26"
Maximum tyre width 14"
Operating Pressure 120-145psi
Weight 259kg
Bead Breaking Force 15500nm
Drive Motor 230V 1PH
