AM-828 Automaster Platinum Edition Wheel balancer

The Automaster  AM-828 Platinum Edition premium quality wheel balancer is designed for mid-high volume professionals, who need a reliable, robust, high-performance fully featured product with great price.

Supplied in dark grey RAL7016

Platinum Edition models are manufactured in China, with some of the key components imported from Italy.

Supplied standard with a Haweka quick nut from Germany

The adhesive weights can be positioned easily and rapidly using the laser line guidance for precise weight placement at  6 o’ clock position.

With the integrated LED illumination you have clear visibility of the work area.

Full automatic measuring of all wheel dimentions with the input of wheel diameter and distance by the arm & width by the sonar for contactless measurement of wheel width.

The electromagnetic autolocking brake hold the wheel in place for ease of weight application.

A Fast & Easy Split (FES) function allows for behind the spokes positioning of weights and a huge combination of Alu Programs

With a choice of three modes for adhesive weights: distance arm clip, with the 6 o’clock laser or manually at 12 o’clock.

Components Made in Italy, Haweka quick nut (Germany)Electronic boards, Picks ups, Rotation sensors, Width sonar, Motor belt, Electric cables and connectors



  • FEATURES

    · Automatic input of wheel diameter and distance by arm

    · Automatic measuring of wheel width by touchless SONAR

    · Laser guidance for precise weight placement

    · LED illumination inside rim for clear visibility

    · Supplied standard with a Haweka quick nut from Germany

    · Electromagnetic autolocking brake for ease of weight application

    · Fast & Easy Split (FES) function allows for behind the spokes positioning of weights

    · Huge combination of Alu Programs.

    · Opposite Weight Function (OWF) allows for 6 o’ clock application of balance weights

    · “No Wheel Needed” (NWN) system for calibrating gauges, without need for any sample wheel.

    · Automatic stop/start via lifting of wheel guard

    · Three modes for adhesive weights: distance arm clip, with the 6 o’clock laser  or manually at 12 o’clock.

    · Opti-match function for best position of the tyre on the rim. (optimization of the unbalance between rim and tyre).

    · Simple self calibration function

    · European CE Safety Certified

    · Full 2 year warranty

    · Components Made in Italy, Haweka quick nut (Germany)Electronic boards, Picks ups, Rotation sensors, Width sonar, Motor belt, Electric cables and connectors



Spinning speed

<150 rpm

Measurement accuracy

1g

Average spin time

5-6s

Rim width

1.5-20”

Rim diameter

10-30”







Power supply voltage

230V 1Phase

Maximum wheel weight

75KG

Shaft diameter

40mm

Machine weight

85kg

Maximum wheel diameter

1100mm (with hood)
